Frequency Response(±1.5dB@20Hz-20KHz)
(频率响应):GROUP,MIX-B,MONO,AUX SEND
T.H.D(<0.1%@+14dB 20Hz-20KHz):
(总谐波失真):GROUP,MIX-B,MONO,AUX SEND
Hum and Noise(Rs=150Ω)(交流噪音):
Equivalent Input Noise:-128dB
GROUP,MIX-B,MONO,AUX SEND
-95dB(Residual Noise)
GROUP,MIX-B,MONO,AUX SEND
(master fader minimum):-80dB(Residual Noise)
Input Sensitivity/Impedance
(输入灵敏度/阻抗):
MIC:-60dB/600Ω(BAL)
LINE:-20dB/10KΩ(BAL)
AUX RETURN:+4dB/10KΩ(UNBAL)
TAPE RETURN:-10dBv/10KΩ(UNBAL)
Output Level/Impedance
(输出电平/阻抗):
MIX L/R,MONO:+4dB/600Ω(BAL)
CTRL ROOM,MIX-B:+4dB/600Ω(BAL)
GROUP:+4dB/600Ω(BAL)
INSERT:0dB/10KΩ
PHONE:3mW/100Ω
Gain Control(增益控制):44dB
Phantom Power(幻像电源):+48vDC(Individual)
Equalizer(均衡器):
(Maximum boost or cut:±15dB)
High:12KHz(shelving)
High-Mid:800-8KHz(sweep)
High-Low:160-1.6KHz(sweep)
Low:80Hz(shelving)
